LESER Best Availability Change-over Valve Type 320
LESER Best Availability Change-over Valve Type 320
LESER Best Availability Change-over Valve Type 320
LESER Best Availability Change-over Valve Type 320

Best Availability

Type 320 Flow

Casted change-over valve

Industries

Approvals

LESER Change-over valves of Type 320 Flow are designed, marked, produced and approved according to the requirements of the following regulations:

  • LESER CE Approvel
  • LESER EAC Approvel
  • LESER CRN Approvel

Technical specifications Type 320 Flow

Nominal Diameter at Inlet
DN 125 - DN 400 | 5'' - 16''
Flange Rating Inlet
PN 10 - PN 250 | CL150 - CL1500
Temperature (in accordance with DIN EN)
-211 to 400 °C | -348 to 752 °F
Temperatur (nach ASME)
-211 to 400 °C | -348 to 752 °F
Body Material
1.0619, 1.4408 | WCB/WCC, LCB, CF8M
Valve Connection
Flange acc. to DIN EN 1092-1 or acc. to ASME B16.5
Approvals
DGRL 2014/68/EU, TR-CU 010, TR-CU 032
LESER Change-over valve Cutting image
