Technical data High Perfomance

Nominal Diameter at Inlet

DN 20 - DN 400 | 3/4" - 16"

Actual Orifice Diameter d₀

18 mm - 295 mm | 0.71 in - 11.61 in

Actual Orifice Area A₀

254 mm² - 68349 mm² | 0.394 in² - 105.942 in²

Pressure

0.1 bar - 300 bar | 1.5 psig - 4,350 psig

Temperature (in accordance with DIN EN)

-270 °C to 550 °C | -454 °F to 1,022 °F

Body Material

0.6025, 0.7043, 1.0619, 1.4408, 1.0460 / 1.0425, 1.4571, 1.4404, 1.4581, 1.7357 | Cast iron, Ductile Gr. 60-40-18, SA 216 WCB, SA 351 CF8M, carbon steel, 316Ti, SA 479 316L, SA 351 CF10M , SA 217 WC6

Valve Connection

Flange in accordance with DIN EN 1092 or ASME B 16.5

Bellows Material (optional)

Stainless steel, elastomer

Load Type

Spring-loaded
