Technical specifications Type 481

入口处的公称直径

DN15 - DN25 | 3/4" - 1"

流道

0.5 x D

實際流道直徑d₀

10 mm | 0.394 in

实际流道面积A₀

78.5 mm² | 0.122 in²

壓力

0.1 - 68 bar | 1.5 - 986 psig

温度(符合DIN EN标准)

-45 to 250 °C | -49 to 482 °F

阀体 材质

1.4404 | SA 479 316L

阀门连接

Clamps acc. to ASME BPE, DIN 32676 or ISO 2852 Threaded connection acc. to DIN ISO 228 or ASME B 1.20.1, Aseptic clamps acc. to DIN 11864 T1 Series A or B (with nut) or DIN 11851, Neumo-Sterile thread (with nut)

装载类型

Spring loaded

批准书

PED/ DIN EN ISO 4126-1, PED/ AD 2000-Merkblatt A2, ASME Sec. VIII Div. 1, CRN, AQSIQ, EAC

特价

Designed and manufactured acc. to: DIN 11866, ASME BPE, EN 1672-2, DIN ISO 14159, USP class VI and FDA 21 CFR
