Technical specifications Type 449
- 入口处的公称直径
- DN 25 - DN 100 | 1" - 4"
- 實際流道直徑d₀
- 23 - 92 mm | 0.91 - 3.62 in
- 实际流道面积A₀
- 416 - 6648 mm² | 0.645 - 10.304 in²
- 壓力
- 0.1 - 16 bar | 1.45 - 232 psig
- 温度(符合DIN EN标准)
- -270 to 450 °C | -121 to 392 °F
- 阀体 材质
- Acc. to customer preference all materials available
- 阀门连接
- Flange acc. to DIN EN 1092-1 or acc. to ASME B 16.5
- 波纹管 材质 (可选项al)
- Stainless steel
- 装载类型
- Spring loaded
- 批准书
- On request
- 特价
- Currently no approvals acc. to ASME
