Modulate Action

Type 431 / 433 PN 160

Safety valve with medium capacities and high proportional opening area for high pressures

批准书

LESER Modulate Action safety valves of Type 431 / 433 PN 160 are designed, marked, produced and approved according to the requirements of the following regulations:

  • LESER CE Approvel
  • LESER EAC Approvel
  • LESER Chinese TS Approvel

Technical specifications Type 431, 433 PN 160

入口处的公称直径
DN 15 | 1/2"
實際流道直徑d₀
12 mm | 0.47 in
实际流道面积A₀
113 mm² | 0.175 in²
壓力
0.3 - 160 bar | 4.35 - 2320.6 psig
法兰等级 入口
PN 63 - PN 160 | CL300 - CL600
温度(符合DIN EN标准)
-270 to 450 °C | -454 to 842 °F
阀体 材质
1.0619, 1.4408
阀门连接
Flange acc. to DIN EN 1092 or acc. to ASME B16.5
波纹管 材质 (可选项al)
Stainless steel and elastomer
装载类型
Spring loaded
批准书
PED/ DIN EN ISO 4126-1, PED/ AD 2000-Merkblatt A2, AQSIQ, EAC
船级社
LR, RINA, DNV GL, BV, ABS
特价
Units converted; No approvals acc. to ASME
